KR1501 Equivalent To Jst ZH1.5 Alternatives connector
KR1501 — Pitch 1.50mm · Circuits 2-16pin · Current 1A · Voltage 100V
Product photos
- Series: KR1501
- Pitch: 1.50mm
- JST Connector Alternatives
- Equivalent to JST
- Pitch
- 1.50mm
- Circuits
- 2-16pin
- Current
- 1A
- Voltage
- 100V
The KR1501 series connector is a highly reliable, compact connector for printed circuit boards. With a pitch of 1.5 mm, a package height of 5.6 mm (top-mounted type), and a thickness of 3.5 mm, the KR1501 series offers significant space savings.The KR1501 series connectors feature a plastic-shell latching method that ensures stable contact and efficient insertion operations. In addition, the series features precise insertion and withdrawal forces for easy assembly and unassembly, while providing excellent electrical performance and resistance to strong tensile and vibration.The KR1501 series connectors are widely used in scenarios such as household appliances, industrial control, and storage and network systems, and are one of the most common connection methods in the field of electronic devices.
Specifications
| Pitch | 1.50mm |
|---|---|
| Circuits | 2-16pin |
| Current | 1A |
| Voltage | 100V |
| Material | PBT/ |
|---|---|
| Insulation O.D | 0.4 to 0.8mm |
| Withstanding Voltage | 500V AC/ |
| Temperature Range | -40℃～+105℃ |
| Contact Resistance | 20m Ω/ |
| Insulation Resistance | 100M Ω/ |
| Product Plating | Gold Flash/ |
Description
With its compact square edge configuration and robust construction, it offers the best option for dense electronic systems. Its compact dimensions not only save a lot of space, but also make it possible to arrange more connection points in a limited area.
Highly flexible, it can be used as a power contact, a signal contact, or both a power and signal contact, or a signal and ground contact. This versatility makes it easy to adapt to a variety of complex electronic systems, ensuring that the harness efficiently interconnects printed circuit boards with a variety of device components that send signals and power.
The use of advanced bonded metal conduit and multiple grounding point design effectively prevents risks such as fire hazards, component damage, overheating and possible electric shock. These safety measures ensure stable system operation while protecting the equipment from potential damage, thus providing users with greater safety and reliability. Whether in harsh operating environments or in application scenarios that require stable operation over long periods of time, the KR1501 series connectors demonstrate excellent performance and reliability.
Contains no hazardous chemicals in concentrations exceeding RoHS limits. This means that the connectors can be processed safely and stably at the high temperatures required for lead-free soldering during manufacturing, which not only complies with environmental requirements, but also ensures product reliability and durability.
Features
- Compact design
- Meets power, signal and ground contact requirements
- Safe and Reliable
- RoHS Compliant
