KRQK000015 Series
Pitch 2.70mm · Circuits 26pin · Current 2A · Voltage 250V
- Pitch
- 2.70mm
- Circuits
- 26pin
- Current
- 2A
- Voltage
- 250V
RPJ connector, 2.70mm pitch wire to wire connector.
Product photos
Specifications
| Pitch | 2.70mm |
|---|---|
| Circuits | 26pin |
| Current | 2A |
| Voltage | 250V |
| Material | PBT/ |
|---|---|
| Insulation O.D | 0.9 to 1.5mm |
| Withstanding Voltage | 1000V AC/ |
| Temperature Range | -40℃～+105℃ |
| Contact Resistance | 20mΩ Max |
| Insulation Resistance | 1000MΩ Min |
| Product Plating | Gold flash over Nickel |
