Specifications

Key specifications
Pitch	1.00mm
Circuits	2-20pin
Current	1A
Voltage	50V

General specification
Material	PA66/PA9T/UL94/Phosphor Bronze
Insulation O.D	0.4 to 0.8mm
Withstanding Voltage	500V AC/ minute
Temperature Range	-40℃～+105℃
Contact Resistance	20mΩ Max
Insulation Resistance	100MΩ Min
Product Plating	Tin plated over Nickel

Description

The KR1005 series connector is a powerful and versatile product. It utilizes advanced technologies and materials, such as PA66/PA9T and Phosphor Bronze, to ensure the durability and stability of the product.The KR1005 series connectors have excellent electrical properties, such as high insulation resistance and low contact resistance, which make them suitable for a wide range of circuit requirements. In addition, its wide temperature adaptability range, from -40°C to +105°C, provides the possibility of applications in a variety of environmental conditions.The KR1005 series connectors are also available in a wide range of models and specifications to meet the needs of different users, and are an important part of electronic equipment and systems.

The KR1005 series connectors have excellent electrical performance, including high insulation resistance and low contact resistance, which ensures stable and reliable signal transmission and reduces the risk of failure due to poor electrical performance.

Made of high-quality materials such as PA66/PA9T and Phosphor Bronze, which have excellent durability and stability to withstand long periods of use and various environmental conditions.

The ability to operate normally over a wide range of temperatures from -40°C to +105°C makes it suitable for a variety of complex and extreme environmental conditions, increasing the reliability and stability of the device.

Provides a variety of specifications and models for users to choose from, which can meet the connection needs of different equipment and systems, providing users with greater flexibility and convenience.

Reasonable design, easy to install, reducing the user’s operating difficulties and time costs. At the same time, it is compact and easy to maintain, which reduces the maintenance cost in the later stage.

The withstand voltage is up to 500V AC/minute, which ensures safe use in high-voltage environments and further improves the reliability and safety of the equipment.

In summary, the KR1005 series connectors have become an important and indispensable part of electronic equipment and systems due to their excellent electrical performance, high durability and stability, wide environmental adaptability, diversified specification options, easy installation and maintenance, and excellent withstand voltage performance.
